OMG LP 09CF 11KG/0.07 8.4V
Referência: OMG-LP-09CF
59,90 €
✅ Disponível em loja física e online
Pagamentos seguros
Envio em 24h
DESCRIÇÃO DO PRODUTO
Metal Coreless Digital servo fit in 1/10 Drift?touring car,
Operating voltage?7.4-8.4V
Operating speed:
7.4V-0.082sec/60'
8.4V-0.077sec/60'
Dynamic torque:
7.4V-10.5kg-cm
8.4V-11.2kg-cm
Horn gear spline?25T
Size?41x20.5x26mm
Weight?55g
Limit angle:180±10°(500-2500μsec)
Rotating direction:180°(1000-2000μsec)
Operating travel :220
Neutral position :1520μsec
Maximum:≈180°(500-2500μsec)
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:200 mm
Operating voltage?7.4-8.4V
Operating speed:
7.4V-0.082sec/60'
8.4V-0.077sec/60'
Dynamic torque:
7.4V-10.5kg-cm
8.4V-11.2kg-cm
Horn gear spline?25T
Size?41x20.5x26mm
Weight?55g
Limit angle:180±10°(500-2500μsec)
Rotating direction:180°(1000-2000μsec)
Operating travel :220
Neutral position :1520μsec
Maximum:≈180°(500-2500μsec)
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:200 mm
OMG-LP-09CF
