HOBBYWING XERUN AXE550L R2-3300KV FOC COMBO FOR ROCK CRAWLER

Referência: HW38020314

262,50 €
Com IVA

✅ Stock Online (Envio 1 a 3 dias úteis)

Quantidade

Adicionar à lista de desejos



Pagamentos seguros



Envio em 24h

Hobbywing Xerun Axe550L R2-3300kV FOC Combo for Rock Crawler
HW38020314


Specifications

Product Name

XERUN AXE R2 Brushless ESC

Product Number

30112102

Type

Scale

1/10th

Brushed/Brushless

BL

Sensored/Sensorless

SD

Waterproof

YES

Specifications

Cont./Peak Current

80A/480A

Input Voltage

2-3S Lipo/6-9 Cell NiMH

BEC Output

Switch Mode:6V/7.4V@6A

Wires & Connectors

Wires & Connectors

Black-14AWG-200mm*1 Red-14AWG-200mm*1

Output Wires

No

Input Connectors

XT60

Output Connectors

No

ESC Programing via

SET Button on ESC

Not Supported

LED Program Box

Not Supported

LCD Program Box

Not Supported

WiFi Module

Not Supported

Programming Port

Built-in bluetooth

Firmware

Firmware Upgrade

Supported

Size & Weight

Size

47.4x36.2x26.5mm

Weight

108g (Including the weight of input line)

Applications

Applications

Only support XERUN AXE R2 motor

Vehicles

1/10thRock Crawler

Product Name XERUN AXE540L R2-1400KV XERUN AXE540L R2-2100KV XERUN AXE540L R2-2800KV XERUN AXE550 R2-3300KV
Scale 1/10th 1/10th 1/10th 1/10th
Product Number 30401253 30401254 30401255 30401256
Brushed/Brushless BL BL BL BL
Sensored/Sensorless SD SD SD SD
Poles 4 4 4 4
KV 1400KV 2100KV 2800KV 3300KV
LiPo Cells 2-3S 2-3S 2-3S 2-3S
No-load Current(A) 1.7 2.7 3.6 4.7
Outer diameter (mm) 36.0(1.42in) 36.0(1.42in) 36.0(1.42in) 36.0(1.42in)
Length (mm) 57.8(2.28in) 57.8(2.28in) 57.8(2.28in) 63.8(2.51in)
Shaft diameter (mm) 3.175(0.125in) 3.175(0.125in) 3.175(0.125in) 5(0.197in)
Exposed shaft length (mm) 16.0(0.63in) 16.0(0.63in) 16.0(0.63in) 16.0(0.63in)
Weight(g) 232g 233g 234g 268g

HW38020314
